Caching using CHI

Monday, Sep 8, 2025| Tags: perl

DISCLAIMER: Image is generated using ChatGPT.


1. Introduction

2. Installation

3. Examples

4. CHI::Cache

5. CHI::Tiered

6. Conclusion


Introduction

This is the third and last post in the series Caching in Perl. If you missed the first two then please follow the links below:


1. Caching using Redis/Valkey

2. Caching using Memcached


In this post, I’m sharing my experience with CHI.

While working on my previous post for Redis, I fell in love with it as I had never used it before.

Then when I started my second post about Memcached, I discovered new things about it, even though I had worked with it in the past.

To be honest, I’m really enjoying this process as I’m learning a lot on this journey.

I saved CHI for last in this series specifically to demonstrate the power of all the caching systems we’ve covered so far.

I must admit, I had never used CHI before, so everything was new to me.

I only knew that it provided some kind of caching layer.

The best part of CHI is that it offers a unified interface for working with multiple caching services.

It is the Swiss Army knife for caching needs and one of the most valuable tools in a modern Perl developer’s toolkit.

CHI helps you decouple your application code from a specific cache implementation.

You write your code to the CHI interface.

And then, you can switch your cache backend from in-memory to memcached to a FastMmap file.

Or even a multi-level cache, by changing just a single line of configuration.

There’s no need to rewrite your get/set calls.


Installation

For the purpose of this post, we would need Valkey and Memcached.

With regard to installation, you can find the details in the post above.

Please find below, quick recaps.

Here is the docker configuration, docker-compose.yml, to create docker container running Valkey.

NOTE: Valkey is the new open source project name for Redis.


version: '3.8'

services:
  valkey:
    image: valkey/valkey:latest
    container_name: valkey
    ports:
      - "6379:6379"
    restart: unless-stopped

Now, we can start the container like below:


$ docker-compose up -d
Creating valkey ... done

We can now install the memcached if missing as below:


$ sudo apt install memcached libmemcached-tools
$ sudo systemctl enable memcached
$ sudo systemctl start memcached
$ sudo systemctl status memcached

We can now install the Perl client as below:


$ cpanm -vS CHI Cache::Memcached::Fast Redis::Fast

Examples

Here is a very simple example showing file-based caching using CHI.

File: chi-file.pl


#!/usr/bin/env perl

use v5.38;
use CHI;

my $cache = CHI->new(driver => 'File', root_dir => '/tmp/my_cache');
my $key   = 'key';

# Clear cache.
$cache->clear;

get($cache, $key);
get($cache, $key);

#
#
# SUBROUTINES

sub get($cache, $key) {
    my $val = $cache->get($key);
    if (defined $val) {
        say "Cache HIT, serving from cache.";
    } else {
        say "Cache MISS, fetching from database.";
        sleep 1; # Simulate slow query
        $val = 'val';
        $cache->set($key, $val);
    }
}

Let’s check the result:


$ perl chi-file.pl
Cache MISS, fetching from database.
Cache HIT, serving from cache.

So far, so good.

But did you notice something new in the code above? The use of driver.

It is the storage backends for CHI. Below is some of the most commonly used backends:


Memory            - Volatile, in-process memory.
File              - On-disk storage.
Memcached / Redis - Distributed caches for multi-process/multi-server environments.
FastMmap          - Shared memory via mmap'd files.
and many more

The killer feature of CHI in my opinion is the support for tiered cache.


How about tiered cache?


Using CHI, we can have 2 levels cache i.e. setting up l1_cache infront of primary cache.

Here is a simple example showing the power of CHI layered caches i.e. Memory and File.

File: chi-l1-cache.pl


#!/usr/bin/env perl

use v5.38;
use Test::More;
use CHI;

my $cache = CHI->new(
    driver   => 'File',
    root_dir => '/tmp/file_cache',
    l1_cache => { driver => 'Memory', global => 1 },
);

$cache->clear;

my $key = 'key';
my $val = 'val';

is($cache->get($key), undef, 'First get miss');

$cache->set($key, $val);
is($cache->get($key), $val, 'Found key after set');

my $file_cache = CHI->new(driver => 'File', root => '/tmp/file_cache');
$file_cache->remove($key);
is($file_cache->get($key), undef, 'Key missing in file cache');

is($cache->get($key), $val, 'Found key in L1 cache');

done_testing;

Time for some action now.


$ perl chi-l1-cache.pl
ok 1 - First get miss
ok 2 - Found key after set
ok 3 - Key missing in file cache
ok 4 - Found key in L1 cache
1..4

CHI::Cache

During my research, one thing keep bothering me about cache operation stats.

It would be handy to know, how many hits and miss per cache.

I found CHI::Stats on MetaCPAN.

Unfortunately it didn’t answer any one of my questions.

May be, it’s time to re-invent the wheel.

This is my initial draft.

File: chi-cache.pl


package CHI::Cache;

use CHI;
use Moo;
use Time::HiRes qw(time);

has 'cache' => (is => 'ro', required => 1);
has 'stats' => (
    is      => 'ro',
    lazy    => 1,
    builder => '_build_stats',
);

sub _build_stats {
    my ($self) = @_;

    my $stats = CHI->stats;
    $stats->enable;

    return $stats;
}

sub label {
    my ($self) = @_;

    return $self->cache->label;
}

sub get {
    my ($self, @args) = @_;

    my $t0   = time;
    my $val  = $self->cache->get(@args);
    my $t1   = time;
    my $data = $self->data;

    $data->{gets}++;
    (defined $val) ? ($data->{hits}++) : ($data->{misses}++);
    $data->{get_time_ms} += int(($t1 - $t0) * 1000);

    return $val;
}

sub set {
    my ($self, @args) = @_;

    my $t0   = time;
    my $val  = $self->cache->set(@args);
    my $t1   = time;
    my $data = $self->data;

    $data->{sets}++;
    $data->{set_time_ms} += int(($t1 - $t0) * 1000);

    return $val;
}

sub data {
    my ($self) = @_;

    return $self->stats->stats_for_driver($self->cache);
}

sub AUTOLOAD {
    our $AUTOLOAD;
    my ($self, @args) = @_;

    my $method = $AUTOLOAD;
    $method =~ s/.*:://;

    return if $method eq 'DESTROY';
    return $self->cache->$method(@args);
}

package main;

use v5.38;
use CHI;
use CHI::Cache;
use Data::Dumper;

my $caches = [
    CHI->new(driver => 'Memory', global   => 1),
    CHI->new(driver => 'File',   root_dir => '/tmp/chi_file_cache'),
];

foreach (@$caches) {
    my $cache = CHI::Cache->new(cache => $_);
    $cache->set('foo', 'bar');
    $cache->get('foo');
    $cache->get('baz');
    say "Cache: ", $cache->label;
    say Dumper($cache->data);
}

Let’s test the script.


$ perl chi-cache.pl
Cache: Memory
$VAR1 = {
          'hits' => 1,
          'set_time_ms' => 0,
          'sets' => 1,
          'misses' => 1,
          'start_time' => 1757341995,
          'gets' => 2,
          'get_time_ms' => 0
        };

Cache: File
$VAR1 = {
          'gets' => 2,
          'get_time_ms' => 0,
          'set_time_ms' => 3,
          'start_time' => 1757341995,
          'sets' => 1,
          'misses' => 1,
          'hits' => 1
        };

Decent result, not a perfect one though.


CHI::Tiered

I was wondering, why limit to just l1_cache.

I decided to work on solution where user can choose how many layers and type of cache to pick.


GitHub Repository: CHI::Tiered


There are two ways to work with CHI::Tiered as below:

First passing list of arrayrefs.


my $cache = CHI::Tiered->new(
    [driver => 'Memory',    global   => 1                  ],
    [driver => 'File',      root_dir => '/tmp/cache'       ],
    [driver => 'Memcached', servers  => ['127.0.0.1:11211']],
);

Or passing list of CHI::Driver objects.


my $memory    = CHI->new(driver => 'Memory',    global   => 1);
my $file      = CHI->new(driver => 'File',      root_dir => '/tmp/cache');
my $memcached = CHI->new(driver => 'Memcached', servers  => ['127.0.0.1:11211']);

my $cache = CHI::Tiered->new($memory, $file, $memcached);

The order of cache is important, fastest to slowest. You can decide the order.

Standard operations are as below:


$cache->set($key, $val, '1 hour');
my $value = $cache->get($key);
$cache->remove($key);
$cache->clear;

Let’s build and test the package CHI::Tiered.


$ perl Makefile.PL
Checking if your kit is complete...
Looks good
Generating a Unix-style Makefile
Writing Makefile for CHI::Tiered
Writing MYMETA.yml and MYMETA.json

$ make
cp lib/CHI/Tiered.pm blib/lib/CHI/Tiered.pm
Manifying 1 pod document

$ make test
PERL_DL_NONLAZY=1 "/usr/bin/perl" "-MExtUtils::Command::MM" "-MTest::Harness" "-e" "undef *Test::Harness::Switches; test_harness(0, 'blib/lib', 'blib/arch')" t/*.t
t/00-load.t ............. 1/1 # Testing CHI::Tiered 0.01, Perl 5.038002, /usr/bin/perl
t/00-load.t ............. ok
t/01_driver_name.t ...... ok
t/02_driver_obj.t ....... ok
t/03_driver_extended.t .. ok
t/manifest.t ............ ok
t/pod.t ................. ok
All tests successful.
Files=6, Tests=39,  0 wallclock secs ( 0.01 usr  0.00 sys +  0.40 cusr  0.07 csys =  0.48 CPU)
Result: PASS

Conclusion

This exercise was worth it. In the end, I have got two solutions: CHI::Cache and CHI::Tiered.

I will try it few times before pushing it to CPAN.

If you have any suggestions, please do share with me: mohammad.anwar@yahoo.com.


Happy Hacking !!!
