TL;DR
How do you make the world’s best Perl ORM non-blocking without rewriting your entire schema? We’ve solved the “DBI Ceiling” by isolating DBIx::Class in a worker pool. Keep your existing Result classes and use $schema->await() to run queries without stopping your heartbeats.
1. Introduction
2. Phase 1: The Async Hash
3. Phase 2: The Object Hybrid
4. Phase 3: The Bridge & Worker Design
5. Modern API
6. Lessons Learned
7. Loop Freeze Test
8. Stress Test
9. Final Retrospective
10. Benchmarks
11. Frequently Asked Questions
Introduction
Before we dive into the details, I want to clarify the philosophy behind this release.
DBIx::Class::Async is not a replacement for DBIx::Class, it is a tribute to it.
DBIx::Class remains the most robust and elegant ORM in the Perl ecosystem. However, as our applications move toward increasingly asynchronous, event-driven architectures, the need to bridge the gap between “standard” blocking DBI calls and the non-blocking event loop became undeniable. This project is about taking that legendary stability and pushing it one step further into the high-concurrency era.
For those following my work, you know I have been deep in the trenches writing my second book on DBIx::Class. I want to share that I made the difficult decision to put the manuscript on hold over the last one month.
Developing the foundation for DBIx::Class::Async proved to be a massive undertaking that demanded all of my FREE time. I believed it was vital to lay this technical foundation first, ensuring that when the book is finally in your hands, it covers the full spectrum of modern Perl database interaction, from classic synchronous patterns to these new parallel horizons.
The foundation is now laid. With the release of v0.50, I am thrilled to return to the manuscript and finish the book. This release isn’t just a new tool; it’s the missing chapter I needed to complete the story of modern DBIC.
This blog post captures the transformation of DBIx::Class::Async from an experimental wrapper to a high-performance, mature asynchronous ORM.
If you’ve ever tried to mix DBIx::Class (DBIC) with an asynchronous event loop like IO::Async or Mojo::IOLoop, you’ve hit the “DBI Ceiling”. No matter how fast your event loop is, standard database drivers are blocking. One heavy query freezes your entire application.
Today, I’m walking through the journey of how we broke that ceiling, moving from a simple “Async Hash” to a sophisticated Bridge & Worker architecture.
Phase 1: The Async Hash
In the beginning (v0.01), the goal was simple: get data out of the database without blocking. The first iteration returned raw hashrefs. It was fast, but it didn’t feel like Perl. We lost the “magic” of DBIC, the relationships, the accessors, and the object-oriented feel.
Phase 2: The Object Hybrid
We tried to bring back the magic by creating a custom Row.pm. This was a “fat” object that tried to mimic a real DBIC row.
The Strategy: Dynamic Accessors
We used AUTOLOAD and symbol table manipulation to create methods on the fly. If you called $user->name, the row would look into its internal _data hashref and return the value.
# v0.02
sub _ensure_accessors {
my $self = shift;
my $source = $self->{schema}->source($self->{source_name});
foreach my $col ($source->columns) {
*{"${class}::$col"} = sub { shift->get_column($col) };
}
}
The Breaking Point
This phase taught us a hard lesson about Memory Leaks. Because every Row object held a reference to the schema and the async_db connection, we created massive circular dependencies. In a resultset of 1,000 rows, the memory usage skyrocketed, and the “Great Worker Leak” began.
Phase 3: The Bridge & Worker Design
The breakthrough came when we stopped trying to make DBI async and started treating it as a distributed service.
The Architecture
We moved to a Worker-Pool Model. The main process (The Bridge) acts as a traffic controller. It never touches the database. Instead, it ships “recipes” to a pool of background workers.
Why v0.50 is more mature now?
-
Zero Loop Freezing: Even a 30-second query won’t lag your UI or network requests.
-
The Deflator Engine: We built a recursive system that turns “live” DBIC objects into “safe” data structures that can travel across process boundaries.
-
Smart Transactions: With txn_do, you can ship a complete transactional block to a background worker. This ensures that even in an async environment, your complex multi-step operations are executed on a single dedicated connection, maintaining full ACID compliance without stalling your main event loop.
The Modern API
One of the primary goals of v0.50 was to ensure that moving to an asynchronous architecture didn’t feel like learning a new language. The API is designed to be a “drop-in” enhancement: you keep your existing Schema logic, but gain the ability to yield control back to the event loop during database I/O.
Seamless Integration
Setting up the Bridge is straightforward. By passing your existing IO::Async::Loop and your standard DBIx::Class schema class, the module handles the heavy lifting of spawning workers and managing Inter-Process Communication (IPC).
# v0.50
my $loop = IO::Async::Loop->new;
my $schema = DBIx::Class::Async::Schema->connect(
"dbi:SQLite:dbname=test.db", $user, $pass, {},
{
workers => 4,
schema_class => 'MyApp::Schema',
async_loop => $loop,
}
);
Writing Non-Blocking Code
Once connected, you can use the modern async/await pattern (via Future::AsyncAwait) or the built-in $schema->await() helper. In both cases, the main process remains responsive while the worker pool crunches the query.
1. The “Yielding” Difference
While both methods keep the loop alive, they handle the “wait” differently:
-
async/await (Keywords): These use Future::AsyncAwait to suspend the current function. This is truly “zero-overhead” waiting. The stack is saved, the sub is paused, and the loop moves on.
-
$schema->await (Method): This is a “loop-blocker”. It forces the loop to run specifically until that one Future is complete. While it allows other timers to fire, it can lead to “nested loop” issues if you aren’t careful, especially in complex applications.
2. Composition and Chaining
Modern async code often involves running multiple things at once:
# This is easy with keywords
my ($users, $logs) = await Future->wait_all(
$schema->resultset('User')->all,
$schema->resultset('Log')->all
);
Doing this with $schema->await requires more manual management of the Future objects before calling the helper.
Use Future::AsyncAwait for the cleanest, most efficient non-blocking code.
my $users = await $rs->all;
Use $schema->await() if you want to keep your code looking like standard Perl or if you are integrating into a codebase where you can’t add new keywords.
my $users = $schema->await( $rs->all );
Both paths ensure that your “Heartbeat” keeps ticking and your app stays responsive.
Lessons Learned
-
Decouple Early: If the underlying library is blocking, don’t wrap it; isolate it.
-
Watch your References: In Perl, circular references in long-running async processes are silent killers.
-
Serialisation is King: The speed of your async library often depends on how fast you can move data between the worker and the bridge.
The move to v0.50 represents more than just a version bump, it’s a shift in philosophy. We stopped fighting the blocking nature of DBI and started orchestrating around it.
Loop Freeze Test
This script simulates a heavy database query while simultaneously running a “Heartbeat” timer.
-
In v0.02: The Heartbeat will stop ticking while the DB is busy.
-
In v0.50: The Heartbeat will continue to tick every second, even while the DB is crunching data.
#!/usr/bin/env perl
use strict;
use warnings;
use File::Temp;
use IO::Async::Loop;
use Time::HiRes qw(time);
use IO::Async::Timer::Periodic;
use DBIx::Class::Async::Schema;
my $loop = IO::Async::Loop->new;
my ($fh, $db_file) = File::Temp::tempfile(UNLINK => 1);
my $schema = DBIx::Class::Async::Schema->connect(
"dbi:SQLite:dbname=$db_file", undef, undef, {},
{ workers => 2, schema_class => 'TestSchema' });
$schema->await($schema->deploy);
my $start = time;
my $is_alive = 0;
my $heartbeat = IO::Async::Timer::Periodic->new(
interval => 1,
on_tick => sub {
$is_alive = 1;
printf "Heartbeat: Loop is alive at %.2f seconds\n", time - $start;
},
);
$loop->add($heartbeat);
$heartbeat->start;
my $query = $schema->resultset('User')
->search({ 'me.id' => { -in => [ 1 .. 1000 ] } })
->all
->then( sub { $loop->stop if $is_alive })
->on_fail(sub { $loop->stop });
$loop->run;
Output
Heartbeat: Loop is alive at 1.02 seconds
Heartbeat: Loop is alive at 2.05 seconds
Heartbeat: Loop is alive at 3.05 seconds
Heartbeat: Loop is alive at 4.05 seconds
Stress Test
This script creates thousands of row objects in a loop. It uses Memory::Usage to show how v0.50 stays lean compared to the old “Fat Row” objects.
#!/usr/bin/env perl
use strict;
use warnings;
use File::Temp;
use Memory::Usage;
use IO::Async::Loop;
use DBIx::Class::Async::Schema;
my $memory_usage = Memory::Usage->new;
my $loop = IO::Async::Loop->new;
my ($fh, $db_file) = File::Temp::tempfile(SUFFIX => '.db', UNLINK => 1);
my $schema = DBIx::Class::Async::Schema->connect(
"dbi:SQLite:dbname=$db_file", undef, undef, {},
{ workers => 2,
schema_class => 'TestSchema',
async_loop => $loop,
cache_ttl => 60,
},
);
$memory_usage->record('Starting test');
$schema->await($schema->deploy({ add_drop_table => 1 }));
sub stress_test {
for my $i (1..50) {
my $rows = $schema->resultset('User')
->search({}, { rows => 100 })
->get;
if ($i % 10 == 0) {
$memory_usage->record("Iteration $i - 1000 rows processed");
print "Processed " . ($i * 100) . " rows...\n";
}
# In v0.02, these $rows would hang around in memory due to cycles
# In v0.50, they are cleaned up immediately when the scope ends
}
}
stress_test;
$memory_usage->dump;
Output
Processed 1000 rows...
Processed 2000 rows...
Processed 3000 rows...
Processed 4000 rows...
Processed 5000 rows...
time vsz ( diff) rss ( diff) shared ( diff) code ( diff) data ( diff)
0 48964 ( 48964) 44800 ( 44800) 6656 ( 6656) 1868 ( 1868) 38340 ( 38340) Starting test
1 48964 ( 0) 44800 ( 0) 6656 ( 0) 1868 ( 0) 38340 ( 0) Iteration 10 - 1000 rows processed
1 48964 ( 0) 44800 ( 0) 6656 ( 0) 1868 ( 0) 38340 ( 0) Iteration 20 - 1000 rows processed
1 48964 ( 0) 44800 ( 0) 6656 ( 0) 1868 ( 0) 38340 ( 0) Iteration 30 - 1000 rows processed
1 48964 ( 0) 44800 ( 0) 6656 ( 0) 1868 ( 0) 38340 ( 0) Iteration 40 - 1000 rows processed
1 48964 ( 0) 44800 ( 0) 6656 ( 0) 1868 ( 0) 38340 ( 0) Iteration 50 - 1000 rows processed
Final Retrospective
1. The “Don’t Wrap, Isolate” Rule
We initially tried to wrap DBI calls in Futures. We learned that wrapping a blocking call doesn’t make it async; it just makes it a blocking call with a different name. True async requires process or thread isolation.
2. Serialisation is the Tax of Success
Moving to a worker model meant we had to pay a “Serialisation Tax”. We spent a significant amount of time optimising how we stringify and de-stringify data between pipes. The lesson: Pick a fast serialiser (like Sereal) early.
3. API Symmetry Matters
The hardest part wasn’t the backend logic, it was making the $schema->resultset(…) syntax feel identical to the standard version. Users shouldn’t have to learn a new DSL just to go async. By mimicking the DBIC interface perfectly, we reduced the “Cognitive Load” for developers.
4. Health Checks are Mandatory
Workers die. Database connections timeout. In a long-running async daemon, you cannot assume your workers are immortal. Building the ping and re-spawn logic (v0.50) was what finally made this library more mature.
Benchmarks
Numbers in a vacuum can be misleading, so we put DBIx::Class::Async v0.50 through a real-world stress test.
Test Setup
We benchmarked DBIx::Class::Async against standard DBIx::Class using a MySQL database with 10,000 user records.
The test executed 100 complex queries (filtering by age, ordering results, limiting to 100 rows) in both sequential and parallel modes.
The async version used 4 worker processes maintaining persistent MySQL connections, while the standard version executed queries one-by-one on a single connection.
We then run the bench, in three stages: 50 queries, 100 queries and 200 queries.
Here is the breakdown of the benchmark script showing three subroutines i.e. setup_environment(), run_bench() and print_summary().
UPDATED: Script now do data integrity check as well.
sub setup_environment {
my $loop = shift;
print "Setting up MySQL database with 10,000 records...\n\n";
my $dsn = "dbi:mysql:database=testdb";
my $username = "root";
my $password = "root";
my $raw_schema = TestSchema->connect($dsn, $username, $password);
$raw_schema->storage->dbh->do("DROP TABLE IF EXISTS orders");
$raw_schema->storage->dbh->do("DROP TABLE IF EXISTS users");
$raw_schema->deploy({ add_drop_table => 1 });
my @data = map {
{
name => "User $_",
age => 20 + int(rand(60)),
email => "user$_\@example.com",
active => 1
}
} (1..10_000);
$raw_schema->resultset('User')->populate(\@data);
print "Database ready\n\n";
my $async_schema = DBIx::Class::Async::Schema->connect(
$dsn, $username, $password, {},
{ workers => 4, schema_class => 'TestSchema', async_loop => $loop }
);
return $async_schema;
}
sub run_bench {
my ($name, $is_async, $query_count, $raw_schema, $async_schema, $loop) = @_;
print "\n" . "-" x 70 . "\n";
print "$name\n";
print "-" x 70 . "\n";
# Heartbeat configuration
my $ticks = 0;
my $interval = 0.001; # 1ms resolution
my $timer = IO::Async::Timer::Periodic->new(
interval => $interval,
on_tick => sub { $ticks++ },
);
$loop->add($timer->start);
my $t0 = [gettimeofday];
my $total_rows_verified = 0;
my $objects_inflated = 0;
my $heavy_search = sub {
my $schema = shift;
return $schema->resultset('User')->search(
{
age => { '>' => 30 },
active => 1,
name => { -like => '%User%' }
},
{
order_by => { -desc => 'age' },
rows => 100,
columns => [qw/id name email age/]
}
);
};
if ($is_async) {
# Parallel execution
my @futures = map {
$heavy_search->($async_schema)->all
} (1..$query_count);
# Process each future
for my $f (@futures) {
my $rows = $async_schema->await($f);
$total_rows_verified += scalar(@$rows);
if (@$rows && Scalar::Util::blessed($rows->[0])) {
$objects_inflated += scalar(@$rows);
}
}
} else {
# Sequential execution WITH VERIFICATION
for (1..$query_count) {
my @rows = $heavy_search->($raw_schema)->all;
# VERIFY PAYLOAD
$total_rows_verified += scalar(@rows);
if (@rows && Scalar::Util::blessed($rows[0])) {
$objects_inflated += scalar(@rows);
}
}
}
my $elapsed = tv_interval($t0);
$elapsed = 0.0001 if $elapsed <= 0;
$timer->stop;
$loop->remove($timer);
my $expected_ticks = int($elapsed / $interval);
my $responsiveness = $expected_ticks > 0
? ($ticks / $expected_ticks) * 100
: 0;
my $throughput = $query_count / $elapsed;
printf "Execution Time: %.4f seconds\n", $elapsed;
printf "Throughput: %.2f queries/second\n", $throughput;
printf "Data Integrity: %d rows verified (%d objects inflated)\n",
$total_rows_verified, $objects_inflated;
printf "Event Loop Health: %.1f%% responsive (%d/%d ticks)\n",
$responsiveness, $ticks, $expected_ticks;
if (!$is_async) {
$baseline_time = $elapsed;
print "System Status: " . ($ticks == 0 ? "COMPLETELY BLOCKED" : "DEGRADED") . "\n";
print "Performance: [BASELINE]\n";
} else {
my $speedup = $baseline_time / $elapsed;
print "System Status: " . ($responsiveness > 80 ? "HEALTHY" : "BUSY") . "\n";
printf "Performance: %.2fx FASTER than baseline\n", $speedup;
}
push @results, {
name => $name,
is_async => $is_async,
query_count => $query_count,
elapsed => $elapsed,
throughput => $throughput,
responsiveness => $responsiveness,
speedup => $is_async ? ($baseline_time / $elapsed) : 1,
};
}
sub print_summary {
my @results = @_;
print "\n" . "-" x 70 . "\n";
print "SUMMARY\n";
print "-" x 70 . "\n";
my @async_results = grep { $_->{is_async} } @results;
my @sync_results = grep { !$_->{is_async} } @results;
if (@async_results == 0 || @sync_results == 0) {
print "No results to summarize.\n";
exit;
}
my $avg_speedup = 0;
my $max_speedup = 0;
my $avg_responsiveness = 0;
foreach my $result (@async_results) {
$avg_speedup += $result->{speedup};
$max_speedup = $result->{speedup}
if $result->{speedup} > $max_speedup;
$avg_responsiveness += $result->{responsiveness};
}
$avg_speedup /= scalar @async_results;
$avg_responsiveness /= scalar @async_results;
my $total_sync_time = 0;
my $total_async_time = 0;
$total_sync_time += $_->{elapsed} for @sync_results;
$total_async_time += $_->{elapsed} for @async_results;
my $total_time_saved = $total_sync_time - $total_async_time;
my $total_improvement = $total_sync_time > 0
? ($total_time_saved / $total_sync_time * 100)
: 0;
printf "Across all %d test runs:\n", scalar(@results) / 2;
printf "\nPerformance Results:\n";
printf " - Average Speedup: %.2fx faster\n", $avg_speedup;
printf " - Maximum Speedup: %.2fx faster\n", $max_speedup;
printf " - Total Time (Sync): %.4f seconds\n", $total_sync_time;
printf " - Total Time (Async): %.4f seconds\n", $total_async_time;
printf " - Time Saved: %.4f seconds (%.1f%% improvement)\n",
$total_time_saved, $total_improvement;
printf "\nEvent Loop Health:\n";
printf " - Average Responsiveness: %.1f%%\n", $avg_responsiveness;
printf " - Sequential Blocking: 0.0%% (completely blocked)\n";
print "\n What This Means:\n";
print " - TRUE parallel query execution across network connections\n";
if ($avg_speedup > 50) {
printf " - Exceptional performance: %.0fx faster with worker pool\n", $avg_speedup;
print " - Worker process caching and connection reuse is highly effective\n";
}
elsif ($avg_speedup > 2) {
printf " - Strong performance: %.1fx faster with parallelism\n", $avg_speedup;
}
else {
printf " - Similar speed (%.1fx), but with %.1f%% event loop responsiveness\n",
$avg_speedup, $avg_responsiveness;
}
print " - Non-blocking event loop maintains application responsiveness\n";
print " - Better scalability as query count increases\n";
if ($max_speedup > 100) {
print "\nKey Insight: Worker pool caching delivered exceptional results!\n";
print "After warm-up, persistent workers with cached connections and\n";
print "prepared statements achieved extraordinary parallel throughput.\n";
} elsif (@sync_results && $sync_results[0]->{query_count}) {
my $avg_query_time = ($sync_results[0]->{elapsed} / $sync_results[0]->{query_count} * 1000);
print "\nKey Insight: Network latency makes parallelism highly effective!\n";
printf "Each query has ~%.1fms of overhead. With 4 workers, parallel\n", $avg_query_time;
print "execution dramatically reduces total execution time.\n";
}
print "\n";
}
Finally this is my main benchmark script:
#!/usr/bin/env perl
use strict;
use warnings;
use TestSchema;
use IO::Async::Loop;
use DBIx::Class::Async::Schema;
use Time::HiRes qw(gettimeofday tv_interval);
print "DBIx::Class::Async Performance Benchmark (MySQL)\n\n";
print "-" x 70 . "\n";
my $loop = IO::Async::Loop->new;
my ($raw_schema, $async_schema) = setup_environment($loop);
my (@results, $baseline_time);
for my $count (50, 100, 200) {
print "\n" . "Testing with $count queries...\n";
run_bench(
"Standard DBIx::Class (Sequential/Blocking)", 0,
$count, $raw_schema, $async_schema, $loop);
run_bench("DBIx::Class::Async (Parallel/Non-Blocking)", 1,
$count, $raw_schema, $async_schema, $loop);
}
print_summary(@results);
$async_schema->disconnect;
Benchmark with 50 queries
Testing with 50 queries...
----------------------------------------------------------------------
Standard DBIx::Class (Sequential/Blocking)
----------------------------------------------------------------------
Execution Time: 0.1537 seconds
Throughput: 325.33 queries/second
Data Integrity: 5000 rows verified (5000 objects inflated)
Event Loop Health: 0.0% responsive (0/153 ticks)
System Status: COMPLETELY BLOCKED
Performance: [BASELINE]
----------------------------------------------------------------------
DBIx::Class::Async (Parallel/Non-Blocking)
----------------------------------------------------------------------
Execution Time: 0.1535 seconds
Throughput: 325.80 queries/second
Data Integrity: 5000 rows verified (5000 objects inflated)
Event Loop Health: 98.0% responsive (150/153 ticks)
System Status: HEALTHY
Performance: 1.00x FASTER than baseline
Benchmark with 100 queries
Testing with 100 queries...
----------------------------------------------------------------------
Standard DBIx::Class (Sequential/Blocking)
----------------------------------------------------------------------
Execution Time: 0.3071 seconds
Throughput: 325.65 queries/second
Data Integrity: 10000 rows verified (10000 objects inflated)
Event Loop Health: 0.0% responsive (0/307 ticks)
System Status: COMPLETELY BLOCKED
Performance: [BASELINE]
----------------------------------------------------------------------
DBIx::Class::Async (Parallel/Non-Blocking)
----------------------------------------------------------------------
Execution Time: 0.0024 seconds
Throughput: 40899.80 queries/second
Data Integrity: 10000 rows verified (10000 objects inflated)
Event Loop Health: 0.0% responsive (0/2 ticks)
System Status: BUSY
Performance: 125.60x FASTER than baseline
Benchmark with 200 queries
Testing with 200 queries...
----------------------------------------------------------------------
Standard DBIx::Class (Sequential/Blocking)
----------------------------------------------------------------------
Execution Time: 0.6138 seconds
Throughput: 325.83 queries/second
Data Integrity: 20000 rows verified (20000 objects inflated)
Event Loop Health: 0.0% responsive (0/613 ticks)
System Status: COMPLETELY BLOCKED
Performance: [BASELINE]
----------------------------------------------------------------------
DBIx::Class::Async (Parallel/Non-Blocking)
----------------------------------------------------------------------
Execution Time: 0.0047 seconds
Throughput: 42238.65 queries/second
Data Integrity: 20000 rows verified (20000 objects inflated)
Event Loop Health: 0.0% responsive (0/4 ticks)
System Status: BUSY
Performance: 129.64x FASTER than baseline
SUMMARY
Across all 3 test runs:
Performance Results:
- Average Speedup: 85.41x faster
- Maximum Speedup: 129.64x faster
- Total Time (Sync): 1.0746 seconds
- Total Time (Async): 0.1606 seconds
- Time Saved: 0.9139 seconds (85.1% improvement)
Event Loop Health:
- Average Responsiveness: 32.7%
- Sequential Blocking: 0.0% (completely blocked)
What This Means:
- TRUE parallel query execution across network connections
- Exceptional performance: 84x faster with worker pool
- Worker process caching and connection reuse is highly effective
- Non-blocking event loop maintains application responsiveness
- Better scalability as query count increases
Key Insight:
- Worker pool caching delivered exceptional results!
- After warm-up, persistent workers with cached connections and prepared statements achieved extraordinary parallel throughput.
Frequently Asked Questions
Does this work with any DBI driver (PostgreSQL, MySQL, SQLite)?
Yes. Because the blocking DBI calls are isolated within the Worker processes, the Bridge doesn’t care which driver you use. If DBIx::Class supports it, DBIx::Class::Async can handle it. You get true non-blocking behavior even for drivers that don’t have native async support.
How are transactions handled?
Transactions are handled via a specialised txn_do method. Since a transaction must occur on a single database connection, the Bridge ensures that all operations within a txn_do block are pinned to the same Worker until the transaction is committed or rolled back.
What is the performance overhead of the Worker pool?
There is a small serialisation “tax” when moving data between the Worker and the Bridge (IPC). However, for web applications, this is almost always offset by the fact that your main event loop never freezes. We recommend using Sereal or JSON::XS for the fastest possible data transfer.
Can I still use DBIC ResultSource magic (like relationships)?
Partially. You can navigate relationships in your queries, and the returned DBIx::Class::Async::Row objects support basic accessors. However, because the objects are “deflated” to cross the process boundary, “lazy loading” a relationship on a result after it has returned will trigger a new async request rather than a blocking one.
Happy Hacking !!!
