Yesterday, I shared a post about API Gateway using PAGI::FastAPI.
Today, in this post, I will talk about Message Queue.
The latest release of PAGI::FastAPI is v1.2.4. Having said, in the release v1.1.0, we added the support for Message Queue facade.
The distribution shipped with the simple memory-based message queue facade. There is even a handy demo app, i.e. eg/memory_queue_demo.pl.
Let’s take you through the app source code:
First prepare the app and queue:
use v5.38;
use PAGI::FastAPI;
use PAGI::FastAPI::Queue;
use Future::AsyncAwait;
my $app = PAGI::FastAPI->new(
title => 'PAGI Queue Task Processing Service',
version => '1.0.0',
);
my $queue = PAGI::FastAPI::Queue->new( driver => 'Memory' );
Now define the basic app routes:
While working on this post, I found a bug in adding new task. The job_id was null.
I quickly patched the demo app and released PAGI::FastAPI v1.2.5.
Post Task
$app->post('/tasks',
summary => 'Enqueue a background task',
handler => async sub ($c) {
my $item = $c->query_params->{item} // 'default_item';
my $job_data = {
task => 'process_payload',
data => $item,
};
my $job_id = await $queue->push('default', $job_data);
$job_data->{id} = $job_id;
return {
status => 'queued',
job_id => $job_id,
};
}
);
Process Task
$app->post('/tasks/process',
summary => 'Process the next queued task',
handler => async sub ($c) {
my $job = await $queue->pop('default');
unless ($job) {
$c->status(404);
return { error => 'No tasks in queue' };
}
return {
status => 'completed',
job_id => $job->{id},
result => "Processed " . $job->{data},
};
}
);
Task Status
$app->get('/tasks/status',
summary => 'Get current queue status',
handler => async sub ($c) {
my $count = await $queue->size('default');
return {
pending_count => $count,
};
}
);
ACTION TIME
Start Server
$ pagi-server eg/queue_demo.pl
Submit Task
$ curl -X POST "http://127.0.0.1:5000/tasks?item=report_job_1"
{"status":"queued","job_id":1}
Task Status
$ curl "http://127.0.0.1:5000/tasks/status"
{"pending_count":1}
Process Task
$ curl -X POST "http://127.0.0.1:5000/tasks/process"
{"result":"Processed default_item","job_id":1,"status":"completed"}
Now check the status again:
$ curl "http://127.0.0.1:5000/tasks/status"
{"pending_count":0}
Although, it gives you a quick introduction but it is not suitable for serious message queue.
If you are building production grade message queue, I would highly recommend this companion package: PAGI::FastAPI::Queue::Driver::Redis.
Luckily the distribution shipped with a demo app: eg/redis_queue_demo.pl
We will create app and queue as before first:
use v5.38;
use PAGI::FastAPI;
use PAGI::FastAPI::Queue;
use Future::AsyncAwait;
my $app = PAGI::FastAPI->new(
title => 'PAGI Redis Queue Demo',
version => '1.1.0',
);
my $queue = PAGI::FastAPI::Queue->new(
driver => 'PAGI::FastAPI::Queue::Driver::Redis',
options => {
host => '127.0.0.1',
port => 6379,
prefix => 'myapp:queue:',
},
);
my $job_sequence = 0;
Post Task
$app->post('/tasks',
summary => 'Enqueue a task to Redis',
handler => async sub ($c) {
my $item = $c->query_params->{item} // 'default_item';
my $job_id = "job_" . ++$job_sequence . "_" . time();
await $queue->push('default', {
job_id => $job_id,
task => 'process_payload',
data => $item,
});
return {
status => 'queued',
job_id => $job_id,
item => $item,
};
}
);
Process Task
$app->post('/tasks/process',
summary => 'Process next task from Redis',
handler => async sub ($c) {
my $job = await $queue->pop('default');
unless ($job) {
$c->status(404);
return { error => 'No tasks in Redis queue' };
}
return {
status => 'completed',
job_id => $job->{job_id},
result => "Processed " . $job->{data},
};
}
);
Task Status
$app->get('/tasks/status',
summary => 'Get Redis queue status',
handler => async sub ($c) {
my $count = await $queue->size('default');
return {
pending_count => $count,
};
}
);
For this demo, we would also need redis worker.
Here is the script for redis worker: eg/redis_worker.pl
use v5.38;
use PAGI::FastAPI::Queue;
use PAGI::FastAPI::Queue::Driver::Redis;
use Future::AsyncAwait;
use Future::IO;
my $worker_id = $ARGV[0] // $$;
my $queue = PAGI::FastAPI::Queue->new(
driver => 'PAGI::FastAPI::Queue::Driver::Redis',
options => {
host => '127.0.0.1',
port => 6379,
prefix => 'myapp:queue:',
},
);
say "Worker [$worker_id] started. Waiting for jobs...";
while (1) {
my $job = $queue->pop('default')->get;
if ($job) {
my $id = $job->{job_id} // 'N/A';
my $data = $job->{data} // 'N/A';
say "Worker [$worker_id] START processing job ID: $id ($data)";
Future::IO->sleep(1)->get;
say "Worker [$worker_id] FINISHED job ID: $id";
} else {
Future::IO->sleep(0.5)->get;
}
}
ACTION TIME
Before we start the server, we need Redis server first.
Luckily, we have docker compose config file, docker_compose.yml.
Let’s start the Redis in a docker container:
$ docker compose up -d
Start Server
Now time to start the message queue server:
$ pagi-server eg/redis_queue_demo.pl
Submit Task
In another terminal, we will push 10 tasks:
$ for i in {1..10}; \
do \
curl -s -X POST "http://127.0.0.1:5000/tasks?item=job_$i" > /dev/null; \
done
Task Status
$ curl http://127.0.0.1:5000/tasks/status
{"pending_count":10}
Process Task
To process the submitted tasks, we will use two redis worker in separate terminals at the same time, so both workers get equal opportunity to process the tasks:
$ perl eg/redis_worker.pl "A"
Worker [A] started. Waiting for jobs...
Worker [A] START processing job ID: job_1_1787353306 (default_item)
Worker [A] FINISHED job ID: job_1_1787353306
Worker [A] START processing job ID: job_2_1787353306 (default_item)
Worker [A] FINISHED job ID: job_2_1787353306
Worker [A] START processing job ID: job_3_1787353306 (default_item)
Worker [A] FINISHED job ID: job_3_1787353306
Worker [A] START processing job ID: job_5_1787353306 (default_item)
Worker [A] FINISHED job ID: job_5_1787353306
Worker [A] START processing job ID: job_7_1787353306 (default_item)
Worker [A] FINISHED job ID: job_7_1787353306
Worker [A] START processing job ID: job_9_1787353306 (default_item)
Worker [A] FINISHED job ID: job_9_1787353306
$ perl eg/redis_worker.pl "B"
Worker [B] started. Waiting for jobs...
Worker [B] START processing job ID: job_4_1787353306 (default_item)
Worker [B] FINISHED job ID: job_4_1787353306
Worker [B] START processing job ID: job_6_1787353306 (default_item)
Worker [B] FINISHED job ID: job_6_1787353306
Worker [B] START processing job ID: job_8_1787353306 (default_item)
Worker [B] FINISHED job ID: job_8_1787353306
Worker [B] START processing job ID: job_10_1787353306 (default_item)
Worker [B] FINISHED job ID: job_10_1787353306
Finally check the status:
$ curl http://127.0.0.1:5000/tasks/status
{"pending_count":0}
Happy Hacking !!!
