PostgreSQL PGQ

DISCLAIMER: Image is generated using ChatGPT.

A random look around latest changes in PostgreSQL 19 surprised me with new feature Property Graph Queries (PGQ).

My understanding was graph query is best dealt using GraphQL and not by relational database.

But I was wrong, PostgreSQL 19 pleasantly surprised me.

The official release note has all the details: https://www.postgresql.org/docs/19/release-19.html

PGQ is part of SQL Standard ISO/IEC 9075-16

Native SQL/PGQ is a core feature introduced natively starting in PostgreSQL 19.

It bridges the graph world and the relational world.

You feed it graph visual patterns, and it outputs rows and columns that fit directly into standard SQL queries (e.g., SELECT, WHERE, JOIN, or GROUP BY).

GRAPH_TABLE is a table-valued function introduced in the SQL/PGQ standard that allows you to query a property graph using pattern-matching syntax and return the results as a standard relational table.

 SELECT *
   FROM GRAPH_TABLE ( graph_name
        MATCH pattern
        COLUMNS ( projection_list )
   ) AS alias;

Key Components

1. Graph Context (graph_name)

Specifies which defined Property Graph (created via CREATE PROPERTY GRAPH) you are querying.

2. Pattern Matching (MATCH)

Uses visual ASCII-art style pattern expressions to traverse nodes (vertices) and relationships (edges).

Nodes (): Represented by parentheses. You can filter by label (IS person) or conditions (WHERE a.name = ‘Alice’).

Edges -[]->: Represented by arrows and brackets. Direction indicates edge orientation (-[IS follows]->).

Anonymous Nodes (): Used when intermediate step properties aren’t needed in the result.

3. Column Projection (COLUMNS)

Defines what property graph values to extract and output into the resulting table. Each expression must be aliased (a.name AS follower).

How It Works Under the Hood

When PostgreSQL evaluates a GRAPH_TABLE expression, it performs the following steps:

1. Schema Resolution: Looks up graph_name to find mapping rules for vertex and edge tables.

2. Relational Translation: Rewrites MATCH patterns into standard SQL JOIN clauses and WHERE predicates.

3. Execution: Runs the rewritten query against standard relational tables using existing B-tree indexes and query planner optimisations.

Time for some action now.

We need PostgreSQL 19 to begin with. Don’t worry, Docker is your friend.

We can quickly create docker container running PostgreSQL 19 as below:

$ docker run --name pg19-demo \
             -e POSTGRES_PASSWORD=postgres \
             -p 5432:5432 \
             -d postgres:19beta1

Now get the SQL prompt:

$ docker exec -it pg19-demo psql -U postgres
psql (19beta1 (Debian 19~beta1-1.pgdg13+1))
Type "help" for help.

postgres=#

We will create the relational table, users first:

postgres=# CREATE TABLE users (id SERIAL PRIMARY KEY, name TEXT NOT NULL);
CREATE TABLE
postgres=#

Then another table follows as below:

postgres=# CREATE TABLE follows (
    follower_id INT NOT NULL REFERENCES users(id),
    followed_id INT NOT NULL REFERENCES users(id),
    PRIMARY KEY (follower_id, followed_id)
);
CREATE TABLE
postgres=#

Insert sample data now:

postgres=# INSERT INTO users (name) VALUES ('Alice'), ('Bob'), ('Carol'), ('Dave');
INSERT 0 4
postgres=# INSERT INTO follows (follower_id, followed_id) VALUES (1, 2), (2, 3), (1, 4);
INSERT 0 3
postgres=#

Fun starts with defining the property graph:

postgres=# CREATE PROPERTY GRAPH social_graph
  VERTEX TABLES (
    users LABEL person PROPERTIES (id, name)
  )
  EDGE TABLES (
    follows
      SOURCE KEY      (follower_id) REFERENCES users (id)
      DESTINATION KEY (followed_id) REFERENCES users (id)
      LABEL follows
  );
CREATE PROPERTY GRAPH
postgres=#

We got everything setup, let’s query graph relationships using GRAPH_TABLE.

postgres=# SELECT *
FROM GRAPH_TABLE ( social_graph
  MATCH (a IS person WHERE a.name = 'Alice')-[IS follows]->(b IS person)
  COLUMNS (a.name AS follower, b.name AS following)
);
 follower | following
----------+-----------
 Alice    | Bob
 Alice    | Dave
(2 rows)

postgres=#

The same with relational syntax.

postgres=~ SELECT
    a.name AS follower,
    b.name AS following
FROM users a
JOIN follows f ON a.id = f.follower_id
JOIN users b   ON f.followed_id = b.id
WHERE a.name = 'Alice';
 follower | following
----------+-----------
 Alice    | Bob
 Alice    | Dave
(2 rows)

postgres=#

How about Friends of Friends?

postgres=# SELECT fof_name
FROM GRAPH_TABLE ( social_graph
  MATCH (u1 IS person WHERE u1.name = 'Alice')-[IS follows]->()-[IS follows]->(u3 IS person)
  COLUMNS (u3.name AS fof_name)
);
 fof_name
----------
 Carol
(1 row)

postgres=#

Same with relational syntax:

postgres=# SELECT u3.name FROM users u1
JOIN follows f1 ON u1.id = f1.follower_id
JOIN users   u2 ON f1.followed_id = u2.id
JOIN follows f2 ON u2.id = f2.follower_id
JOIN users   u3 ON f2.followed_id = u3.id
WHERE u1.name = 'Alice';
 name
-------
 Carol
(1 row)

postgres=#

Happy Hacking !!!
