I have done multi-part series on Multi-Version Concurrency Control (MVCC) in PostgreSQL couple of months ago.
If you missed it then you can checkout here, if you are interested: Part 1, Part 2 and Part 3
In this post, I will take a closer look at Locking in PostgreSQL database.
Pessimistic Locking
Pessimistic locking is based on the assumption that data contention will occur many times.
Therefore, it places an exclusive lock on the database record immediately after the transaction reads it, which blocks all other transactions from proceeding until that lock is lifted.
The method uses the built-in database approach to locking by means of SQL commands like:
SELECT ... FOR UPDATE;
Other transactions, which want to read or alter this record, will not be able to do anything until the lock is released.
This method is best for the high-contention environment, where there are many conflicts, actions take a short time, and collision mistakes have a serious effect.
The technique eliminates the occurrence of race conditions but raises latency and deadlock levels.
Optimistic Locking
Optimistic locking operates under the belief that instances of data conflict are unlikely to occur.
It permits several transactions to read and change the same record at the same time, i.e. does not lock the row of the database.
Instead, it verifies the existence of conflicting changes only when writing takes place.
It relies on the attribute of the record usually being the version number.
When doing the update, the query checks that the version has not been changed.
In case another transaction updates the row beforehand, the version count will not correspond, affecting 0 rows, and application deals with this failure.
It is most effective for scenarios of high-read and low-write ratio such as long-lasting operation that makes keeping an ongoing database connection useless.
It has very good read throughput coupled with the absence of database locking-related issues, although it necessitates retry mechanism in the application in case of write conflicts.
Setup Database
First we need docker configuration, docker-compose.yml as below:
services:
postgres-db:
image: postgres:latest
container_name: demo_postgres
restart: always
environment:
POSTGRES_USER: demo_user
POSTGRES_PASSWORD: demo_password
POSTGRES_DB: demo_db
ports:
- "5434:5432"
volumes:
pgdata:
Let’s start the container now:
$ docker compose up -d
[+] up 2/2
✔ Network optimistic-locking_default Created 0.0s
✔ Container demo_postgres Started 0.3s
$
Check the container status:
$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
52b8ce5d60de postgres:latest "docker-entrypoint.s…" 6 seconds ago Up 5 seconds 0.0.0.0:5434->5432/tcp, [::]:5434->5432/tcp demo_postgres
Let’s get the database connection first:
$ docker exec -it demo_postgres psql -U demo_user -d demo_db
psql (18.4 (Debian 18.4-1.pgdg13+1))
Type "help" for help.
demo_db=#
We will create the sample table with data:
demo_db=# CREATE TABLE inventory (
id INT PRIMARY KEY,
item_name TEXT NOT NULL,
stock INT NOT NULL,
version INT NOT NULL DEFAULT 1
);
CREATE TABLE
demo_db=# INSERT INTO inventory (id, item_name, stock, version) VALUES (1, 'Laptop', 10, 1);
INSERT 0 1
demo_db=#
Demo Pessimistic Locking
For this we need to create two sessions.
Below is the Session 1:
$ docker exec -it demo_postgres psql -U demo_user -d demo_db -v PROMPT1='Session 1> '
psql (18.4 (Debian 18.4-1.pgdg13+1))
Type "help" for help.
Session 1>
And then the Session 2 as below:
$ docker exec -it demo_postgres psql -U demo_user -d demo_db -v PROMPT1='Session 2> '
psql (18.4 (Debian 18.4-1.pgdg13+1))
Type "help" for help.
Session 2>
Now that we have two sessions open, we will start with Session 1 first.
Session 1> BEGIN;
BEGIN
Session 1> SELECT * FROM inventory WHERE id = 1 FOR UPDATE;
id | item_name | stock | version
----+-----------+-------+---------
1 | Laptop | 10 | 1
(1 row)
In Session 2, we will start another transaction as below:
Session 2> BEGIN;
BEGIN
Session 2> SELECT * FROM inventory WHERE id = 1 FOR UPDATE;
If you noticed, we don’t get the result in Session 2 as the row is locked in Session 1.
Let’s update the row and commit the changes in Session 1.
Session 1> UPDATE inventory SET stock = stock - 1 WHERE id = 1;
UPDATE 1
Session 1> COMMIT;
COMMIT
As soon as we commit the changes in Session 1, you see the updated row in Session 2 as below:
Session 2> SELECT * FROM inventory WHERE id = 1 FOR UPDATE;
id | item_name | stock | version
----+-----------+-------+---------
1 | Laptop | 9 | 1
(1 row)
Now, let’s update the row and commit the changes in Session 2 as well:
Session 2> UPDATE inventory SET stock = stock - 1 WHERE id = 1;
UPDATE 1
Session 2> COMMIT;
COMMIT
Finally we check the row now.
Session 2> SELECT * FROM inventory;
id | item_name | stock | version
----+-----------+-------+---------
1 | Laptop | 8 | 1
(1 row)
Demo Optimistic Locking
Let’s update the row in Session 1 first.
Session 1> SELECT * FROM inventory WHERE id = 1;
id | item_name | stock | version
----+-----------+-------+---------
1 | Laptop | 8 | 1
(1 row)
Session 1> UPDATE inventory
SET stock = stock - 1,
version = version + 1
WHERE id = 1
AND version = 1;
UPDATE 1
Now in Session 2, let’s try to update the same row.
Session 2> UPDATE inventory
SET stock = stock - 1,
version = version + 1
WHERE id = 1
AND version = 1;
UPDATE 0
Because the query returned UPDATE 0, the application detects that another transaction modified the row first.
Session 2’s application code can now roll back, re-fetch the latest data (version = 2), and re-apply its logic.
Happy Hacking !!!
