On the subject of GraphQL, I have written two blog posts so far:
In the first post, I used a plain hash as mock data store. In the second, I upgraded to a real database using a DBIx::Class layer.
It was a big improvement, but there were still a lot of moving parts scattered all over the place.
While working on that second post, I decided to clean things up and hide the complexity inside a separate module.
I was also nudged by fellow Perl enthusiasts who noted:
It will be nice if the some way could be found automate derive the GraphQL Types from the Schema definations
Thanks to that push, I have finally released a new CPAN module: DBIx::Class::Schema::GraphQL
Using this module, we can rewrite the example from the previous post as shown below:
Note, we are keeping the exact same structure as before.
lib/
└── Library
├── Schema
│ └── Result
│ ├── Author.pm
│ └── Book.pm
└── Schema.pm
Schema Class: lib/Library/Schema.pm
package Library::Schema;
use strict;
use warnings;
use base 'DBIx::Class::Schema';
__PACKAGE__->load_namespaces;
1;
Result Class: lib/Library/Schema/Result/Author.pm
package Library::Schema::Result::Author;
use base qw(DBIx::Class::Core);
__PACKAGE__->table('authors');
__PACKAGE__->add_columns(
id => { data_type => 'integer', is_auto_increment => 1 },
name => { data_type => 'varchar', size => 255 },
);
__PACKAGE__->set_primary_key('id');
__PACKAGE__->has_many(books => 'Library::Schema::Result::Book', 'author_id');
1;
Result Class: lib/Library/Schema/Result/Book.pm
package Library::Schema::Result::Book;
use base qw(DBIx::Class::Core);
__PACKAGE__->table('books');
__PACKAGE__->add_columns(
id => { data_type => 'integer', is_auto_increment => 1 },
title => { data_type => 'varchar', size => 255 },
author_id => { data_type => 'integer' },
);
__PACKAGE__->set_primary_key('id');
__PACKAGE__->belongs_to(author => 'Library::Schema::Result::Author', 'author_id');
1;
We just need to install the module now:
$ cpanm -vS DBIx::Class::Schema::GraphQL
Setup
Let’s setup the application first:
File: mojo-app-v3.pl
#!/usr/bin/env perl
use Mojolicious::Lite -signatures;
use JSON::PP;
use DBIx::Class::Schema::GraphQL;
use GraphQL::Execution qw(execute);
use lib 'lib/';
use Library::Schema;
my $db = Library::Schema->connect('dbi:SQLite:dbname=:memory:', '', '');
$db->deploy;
$db->resultset('Author')->create({
name => "J.R.R. Tolkien",
books => [{ title => "The Hobbit" }]
});
$db->resultset('Author')->create({
name => "Isaac Asimov",
books => [{ title => "Foundation" }]
});
$db->resultset('Author')->create({
name => "Damian Conway",
books => [{ title => "Perl Best Practices" }]
});
Nothing much changed, just less imports.
Build the GraphQL schema
my $gql = DBIx::Class::Schema::GraphQL->to_graphql($db);
my $schema = $gql->{schema};
my $ctx = $gql->{context};
Define Web Route
post '/graphql' => sub ($c) {
my $payload = $c->req->json;
my $query = $payload->{query} // '';
my $variables = $payload->{variables} // {};
my $operation = $payload->{operationName};
unless ($query) {
return $c->render(
status => 400,
json => { errors => [{ message => 'No query provided' }] },
);
}
my $result = execute(
$schema,
$query,
undef, # root value
$ctx, # context, passed to every resolver
$variables,
$operation,
);
# HTTP 200 even for GraphQL errors (per spec); only 500 on a completely
# unexpected exception where $result itself is undef.
my $status = $result ? 200 : 500;
$result //= { errors => [{ message => 'Internal server error' }] };
$c->res->headers->content_type('application/json');
$c->render(status => $status, text => JSON::PP->new->pretty->encode($result));
};
get '/graphql' => sub ($c) {
$c->render(inline => <<'EOF');
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="utf-8" />
<title>GraphiQL Playground</title>
<style>
body { height: 100vh; margin: 0; overflow: hidden; }
#graphiql { height: 100%; }
</style>
<link rel="stylesheet" href="https://cdnjs.cloudflare.com/ajax/libs/graphiql/3.0.7/graphiql.min.css" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/react/18.2.0/umd/react.production.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/react-dom/18.2.0/umd/react-dom.production.min.js"></script>
<script src="https://cdnjs.cloudflare.com/ajax/libs/graphiql/3.0.7/graphiql.min.js"></script>
</head>
<body>
<div id="graphiql">Loading...</div>
<script>
window.addEventListener('load', function() {
const fetcher = GraphiQL.createFetcher({ url: '/graphql' });
const root = ReactDOM.createRoot(document.getElementById('graphiql'));
root.render(
React.createElement(GraphiQL, {
fetcher: fetcher,
defaultEditorToolsVisibility: true
})
);
});
</script>
</body>
</html>
EOF
};
The application looks so light and easy to follow.
Start App
app->start;
Let’s start the application as below:
$ perl mojo-app-v3.pl daemon
[2026-06-07 15:13:22.85508] [702292] [info] Listening at "http://*:3000"
Web application available at http://127.0.0.1:3000
For testing, you can use GraphiQL, in-browser IDE by visiting http://127.0.0.1:3000/graphql.
Let’s show the result using command prompt:
Find a Book
$ curl -X POST http://127.0.0.1:3000/graphql \
-H "Content-Type: application/json" \
-d '{"query": "{ book(id: 2) { title author { id name } } }"}'
{
"data" : {
"book" : {
"title" : "Foundation",
"author" : {
"id" : 2,
"name" : "Isaac Asimov"
}
}
}
}
For GraphiQL, you can use this:
{ book(id: 2) { title author { id name } } }
List all Books
$ curl -X POST http://127.0.0.1:3000/graphql \
-H "Content-Type: application/json" \
-d '{"query": "{ allBooks { total nodes { id title author { id name } } } }"}'
{
"data" : {
"allBooks" : {
"total" : 3,
"nodes" : [
{
"id" : 1,
"author" : {
"id" : 1,
"name" : "J.R.R. Tolkien"
},
"title" : "The Hobbit"
},
{
"author" : {
"id" : 2,
"name" : "Isaac Asimov"
},
"id" : 2,
"title" : "Foundation"
},
{
"title" : "Perl Best Practices",
"id" : 3,
"author" : {
"name" : "Damian Conway",
"id" : 3
}
}
]
}
}
}
For GraphiQL, you can use this:
{ allBooks { total nodes { id title author { id name } } } }
Find an Author
$ curl -X POST http://127.0.0.1:3000/graphql \
-H "Content-Type: application/json" \
-d '{"query": "{ author(id: 1) { id name books { id title } } }"}'
{
"data" : {
"author" : {
"books" : [
{
"title" : "The Hobbit",
"id" : 1
}
],
"name" : "J.R.R. Tolkien",
"id" : 1
}
}
}
For GraphiQL, you can use this:
{ author(id: 1) { id name books { id title } } }
List all Authors
$ curl -X POST http://127.0.0.1:3000/graphql \
-H "Content-Type: application/json" \
-d '{"query": "{ allAuthors { total nodes { id name books { id title } } } }"}'
{
"data" : {
"allAuthors" : {
"total" : 3,
"nodes" : [
{
"id" : 1,
"name" : "J.R.R. Tolkien",
"books" : [
{
"id" : 1,
"title" : "The Hobbit"
}
]
},
{
"books" : [
{
"title" : "Foundation",
"id" : 2
}
],
"name" : "Isaac Asimov",
"id" : 2
},
{
"id" : 3,
"name" : "Damian Conway",
"books" : [
{
"title" : "Perl Best Practices",
"id" : 3
}
]
}
]
}
}
}
For GraphiQL, you can use this:
{ allAuthors { total nodes { id name books { id title } } } }
Happy Hacking !!!
