Having done two parts, Part 1 and Part 2, of the series on PostgreSQL MVCC, here is the final post of the series.
In this post, I will talk about Row Locking and how we can use xmin/xmax to decode the process.
Just like in other posts, we will use the PostgreSQL database running inside the Docker container. Also we will use the same table mvcc_demo.
We need two sessions, Session A and Session B for demo purpose.
Session A
$ docker exec -it mvcc_test psql -U postgres
psql (18.4 (Debian 18.4-1.pgdg13+1))
Type "help" for help.
postgres=#
Session B
$ docker exec -it mvcc_test psql -U postgres
psql (18.4 (Debian 18.4-1.pgdg13+1))
Type "help" for help.
postgres=#
Now let’s setup the demo table and extension as below in Session A:
postgreq=# CREATE EXTENSION IF NOT EXISTS pageinspect;
CREATE EXTENSION
postgres=# CREATE TABLE mvcc_demo (id INT PRIMARY KEY, balance INT);
CREATE TABLE
postgres=# INSERT INTO mvcc_demo (id, balance) VALUES (1, 100);
INSERT 0 1
Right after your insert, let’s see what PostgreSQL stored in Session A:
postgres=*# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
831 | 0 | 1 | 100
(1 row)
xmin = 831: The row was born in transaction831.
xmax = 0: The row is fresh and completely unlocked.
Before we proceed, let’s confirm, we have only one version of the row in the heap page.
postgres=# SELECT lp, t_xmin, t_xmax, t_ctid FROM heap_page_items(get_raw_page('mvcc_demo', 0));
lp | t_xmin | t_xmax | t_ctid
----+--------+--------+--------
1 | 831 | 0 | (0,1)
(1 row)
t_ctid = (0,1): Meaning disk block0and line pointer(lp = 1).
t_ctid value is represented as a pair of integers, (page number, line pointer index).
Implicit Row Lock
When you update a row, PostgreSQL implicitly locks it so no other transaction can modify it simultaneously.
In Session A, let’s start a new transaction and update the balance.
postgres=# BEGIN;
BEGIN
postgres=*# UPDATE mvcc_demo SET balance = 150 WHERE id = 1;
UPDATE 1
Let’s check what we see in Session B:
postgres=# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
831 | 832 | 1 | 100
(1 row)
So what has changed?
We now have xmax = 832 for id = 1.
What does that mean?
It means, Session A, created a new transaction (id = 832) and assigned to xmax so no other transaction can touch this row until we COMMIT or ROLLBACK in Session A.
Do you remember, UPDATE is internally treated as DELETE + INSERT?
So we must have 2 versions of this row.
postgres=# SELECT lp, t_xmin, t_xmax, t_ctid FROM heap_page_items(get_raw_page('mvcc_demo', 0));
lp | t_xmin | t_xmax | t_ctid
----+--------+--------+--------
1 | 831 | 832 | (0,2)
2 | 832 | 0 | (0,2)
(2 rows)
Here lp = 1, is the DELETE and lp = 2 is the INSERT. The important bit is, transaction (id = 832), lock this row.
Let’s end the transaction in Session A now:
postgres=*# COMMIT;
COMMIT
We will check the row in Session B now:
postgres=# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 0 | 1 | 150
(1 row)
If you remember, earlier we had, (xmin = 831, xmax = 832) and after completing the transaction, we have (xmin = 832, xmax = 0).
xmin = 832, means row created by transaction(id = 832).
xmax = 0, means it is active and unlocked row.
Explicit Exclusive Lock
Sometimes you want to lock a row to prevent modifications, but you aren’t ready to change the data yet.
In Session A, let’s lock the row explicitly.
postgres=# BEGIN;
BEGIN
postgres=*# SELECT id, balance FROM mvcc_demo WHERE id = 1 FOR UPDATE;
id | balance
----+---------
1 | 150
(1 row)
In Session B, we will inspect the row:
postgres=# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 833 | 1 | 150
(1 row)
We now have xmax = 833, the transaction where we take exclusive lock by SELECT .... FOR UPDATE statement in Session A.
Let’s release the lock in Session A and then check what we have.
postgres=*# ROLLBACK;
ROLLBACK
postgres=# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 833 | 1 | 150
(1 row)
Why we still have xmax = 833, although we released the lock?
To get, xmax = 0, we need to vacuum the table first.
postgres=# VACUUM mvcc_demo;
VACUUM
postgres=# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 0 | 1 | 150
(1 row)
Explicit Shared Lock
What if you want to lock a row so nobody can change it, but you don’t mind if other transactions read or share the lock?
Let’s start a new transaction in Session A as below:
postgres=# BEGIN;
BEGIN
postgres=*# SELECT id, balance FROM mvcc_demo WHERE id = 1 FOR SHARE;
id | balance
----+---------
1 | 150
(1 row)
Let’s check the internals for the lock:
postgres=*# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 833 | 1 | 150
(1 row)
So the row has shared lock by transaction (id = 833).
Now we will try to take shared lock of the same row (id = 1) in Session B.
postgres=# BEGIN;
BEGIN
postgres=*# SELECT id, balance FROM mvcc_demo WHERE id = 1 FOR SHARE;
id | balance
----+---------
1 | 150
(1 row)
Check again the internals:
postgres=*# SELECT xmin, xmax, id, balance FROM mvcc_demo;
xmin | xmax | id | balance
------+------+----+---------
832 | 4 | 1 | 150
(1 row)
This is odd looking xmax?
Earlier in Session A when we took shared lock of row (id = 1), we got the transaction (id = 833) from the Session A.
But when we took shared lock of the same in Session B, we didn’t get transaction id, something like 834.
Instead, we got xmax = 4.
If multiple transactions hold a shared lock on the same row, PostgreSQL can’t just write a single transaction id into xmax.
Instead, it creates a MultiXact ID (mxid).
So, xmax column gets mxid rather than two transaction ids.
How do I know if the xmax column has transaction id or mxid?
There is another internal column t_infomask that we can use to check that.
postgres=# SELECT
lp,
t_xmin,
t_xmax,
t_infomask,
(t_infomask & 4096) > 0 AS is_multixact
FROM heap_page_items(get_raw_page('mvcc_demo', 0));
lp | t_xmin | t_xmax | t_infomask | is_multixact
----+--------+--------+------------+--------------
1 | 832 | 4 | 4560 | t
(1 row)
How to find out all the transaction ids this mxid = 4 contains?
postgres=# SELECT * FROM pg_get_multixact_members('4');
xid | mode
-----+------
833 | sh
834 | sh
(2 rows)
The mode sh means shared.
So now, we know the row (id = 1) has shared lock by two transactions 833 and 834.
There are still more to explore but I will stop for now.
Please check the official document for more information: https://www.postgresql.org/docs/18/explicit-locking.html
